| Model | BC0.9 | BC1.5 |
| Pixel Pitch(mm) | 0.9 | 1.58 |
| Physical Density(dot/m2) | 1101030 | 396384 |
| LED Type | 4 in 1 Mini LED | 4 in 1 SMD1010 |
| Module Size(mm*mm) | 152*171 | 152*171 |
| Horizontal Viewing Angle(Deg) | 140 | 140 |
| Vertical Viewing Angle(Deg) | 140 | 140 |
| Brightness(cd/m2) | 900 | 1500 |
| Gray Scale | 16 | 16 |
| Refresh Rate(Hz) | 3840 | 3840 |
| Maximum Power Consumption | 725W/m2 | 725W/m2 |
| Average Power Consumption | 215W/m2 | 215W/m2 |
| Cabinet Size(mm*mm*mm) | 609*343*60 | 609*343*60 |
| Cabinet Weight(±0.25kg) | 6.5 | 6.5 |
| Cabinet Resolution(px*px) | 640*360 | 384*216 |
| Maintenance | Front / Rear | Front / Rear |
| Working Environment | Indoor | Indoor |
| Certificates | EMC/FCC/ETL | EMC/FCC/ETL |
