| Pixel Pitxh (mm) | P6.8 | P8.3 | P10 | P16.7 | ||
| Physical Density(dot/m²) | 21316 | 14400 | 10000 | 3600 | ||
| LED Type | SMD2727 | SMD3535 | SMD3535 | SMD3535 | ||
| Module Size(mm*mm) | 300*300 | 300*300 | 300*300 | 300*300 | ||
| Cabinet Size(mm*mm) | 1200*1200*90 /600*1200*90 1200*900*90 /600*900*90 1200*600*90 /600*600*90 | |||||
| Cabinet Weight(±0.25kg) | 27 | 27 | 27 | 27 | ||
| Viewing Angle(°) | 150(H)*140(V) | 150(H)*140(V) | 150(H)*140(V) | 150(H)*140(V) | ||
| Gray Scale (bit) | 14 | 14 | 14 | 14 | ||
| Brightness (nits) | 7000 | 7500-10000 | 7500-10000 | 7500-10000 | ||
| Refresh Rate (Hz) | ≥1920 | ≥1920 | ≥1920 | ≥1920 | ||
| Max. Cabinet Power Consumption (W) | 600 | 600 | 600 | 600 | ||
| Average Cabinet Power Consumption (W) | 240 | 240 | 240 | 240 | ||
| Refresh Rate (Hz) | 1920-3840 | 1920-3840 | 1920-3840 | 1920-3840 | ||
| Input Viltage (AC) | 100-240V | 100-240V | 100-240V | 100-240V | ||
| Working Temperature(°C) | -20~+60 | -20~+60 | -20~+60 | -20~+60 | ||
| Working Humidity(RH) | 10%-85% | 10%-85% | 10%-85% | 10%-85% | ||
| Ingress Protection* | IP65 | IP65 | IP65 | IP65 | ||
| Certificates | ELT/FCC | ELT/FCC | ELT/FCC | ELT/FCC | ||
| * Above detials only for reference. | ||||||
