| Product Model | W1.9 | W2.6 | W2.9 | W3.9 | W4.8 | W3.9-OD | W4.8-OD |
| Pixel pitch | 1.9 | 2.6 | 2.9 | 3.9 | 4.8 | 3.9-OD | 4.8-OD |
| Pixel Density (dot/m2) | 262144 | 147456 | 112896 | 66536 | 43264 | 66536 | 43264 |
| LED Type | SMD1515 | SMD2121 | SMD2121 | SMD2121 | SMD2121 | SMD2921 | SMD2921 |
| Module size (mm) | 250*250 | 250*250 | 250*250 | 250*250 | 250*250 | 250*250 | 250*250 |
| Module Resolution | 128*128 | 96*96 | 84*84 | 64*64 | 52*52 | 64*64 | 52*52 |
| Viewing angle (Deg) | 160 H / 120 V | 160 H / 120 V | 160 H / 120 V | 160 H / 120 V | 160 H / 120 V | 160 H / 120 V | 160 H / 120 V |
| Brightness (cd/m2) | 1,000 | 1,000 | 1,000 | 1,000 | 1,000 | 4,500 | 4,500 |
| Grey scale (bit) | 16 | 16 | 16 | 16 | 16 | 16 | 16 |
| Refresh rate (Hz) | 3840 | 3840 | 3840 | 1920-3840 | 1920-3840 | 1920-3840 | 1920-3840 |
| Maximum AC power consumption (W) | 400 | 400 | 400 | 400 | 400 | 700 | 700 |
| Average AC power consumption (W) | 120 | 120 | 120 | 120 | 120 | 210 | 210 |
| Cabinet Size (mm) | 500*500*73 | 500*500*73 | 500*500*73 | 500*500*73 /500*1000*73 | 500*500*73 /500*1000*73 | 500*500*72 | 500*500*72 |
| Cabinet Weight (±0.25KG) | 8 | 8 | 8 | 8/12 | 8/12 | 8.6 | 8.6 |
| Cabinet Resolution (px*px) | 256*256 | 192*192 | 168*168 | 128*128 /128*256 | 104*104 104*208 | 128*128 | 104*104 |
| Working Environment | Indoor | Indoor | Indoor | Indoor | Indoor | Indoor | Indoor |
| Certificates | EMC | EMC | EMC | EMC | EMC | EMC | EMC |
