| Pixel Pitxh (mm) | 1.56 | 1.875 | 2 | 2.5 | 3 | 4 | 5 |
| Pixel Density (dot/m²) | 409600 | 284089 | 250000 | 160000 | 160000 | 160000 | 40000 |
| LED type | SMD1010 | SMD1010 | SMD1515 | SMD1515 | SMD1515 | SMD2020 | SMD2020 |
| Module Size (mm*mm) | 200*150 | 240*120 | 240*120 | 240*120 | 240*120 | 240*120 | 320*160 |
| Module Resolution (dots) | 128*96 | 128*64 | 120*60 | 96*48 | 80*40 | 60*30 | 64*32 |
| Cabinet Thickness (mm) | 90 | 90 | 90 | 90 | 90 | 90 | 90 |
| Maintenance Way | Front | Front | Front | Front | Front | Front | Front |
| Viewing Angle | H140°/V140° | H140°/V140° | H140°/V140° | H140°/V140° | H140°/V140° | H140°/V140° | H140°/V140° |
| Veiwing Angle (Deg) | 160/120 | 160/120 | 160/120 | 160/120 | 160/120 | 160/120 | |
| Brightness (cd/m²) | 800-1,000 | 800-1,000 | 800-1,000 | 800-1,000 | 800-1,000 | 800-1,000 | 800-1,000 |
| Gray Scale (bits) | 16 | 16 | 16 | 16 | 16 | 16 | 16 |
| Refresh Rate (Hz) | 3840 | 3840 | 3840 | 3840 | 3840 | 3840 | 3840 |
| Scan Way | 1/32 | 1/32 | 1/30 | 1/24 | 1/20 | 1/15 | 1/16 |
| Input Voltage (AC) | 100-240V | 100-240V | 100-240V | 100-240V | 100-240V | 100-240V | 100-240V |
| Ingress Protection | IP31 | IP31 | IP31 | IP31 | IP31 | IP31 | IP31 |
| Working Environment | Indoor | Indoor | Indoor | Indoor | Indoor | Indoor | Indoor |
| Life Span (hours) | > 100,000 | > 100,000 | > 100,000 | > 100,000 | > 100,000 | > 100,000 | > 100,000 |
| MTBF (hours) | > 10,000 | > 10,000 | > 10,000 | > 10,000 | > 10,000 | > 10,000 | > 10,000 |
