| Model | UF6.6 | UF8.3 | UF10 | UF16.6 |
| Pixel Pitch (mm) | 6.66 | 8.33 | 10 | 16.66 |
| Pixel Density (dot/m2) | 22500 | 14400 | 10000 | 3600 |
| LED Type | SMD2727 | SMD2727 | SMD3535 | DIP346 |
| Module Size | 200*400 | 200*400 | 200*400 | 200*400 |
| Horizontal Viewing Angle (Deg) | 140 | 140 | 140 | 100 |
| Vertical Viewing Angle (Deg) | Up20° Down60° | Up20° Down60° | Up20° Down60° | Up20° Down60° |
| Brightness (cd/m2) | 5000-6000 | 5500-6500 | 5500-6500 | 8000-9000 |
| Grey Scale (bit) | 16 | 14 | 14 | 14 |
| Refresh Rate (Hz) | ≥1920 | ≥1920 | ≥1920 | ≥1920 |
| Maximun Cabinet Power Consumption (w/sqm) | 500(800*800) | 900(1200*1200) | 1000(1200*1200) | 900(1200*1200) |
| Average Cabinet Power Consumption (w/sqm) | 175(800*800) | 360(1200*1200) | 400(1200*1200) | 360(1200*1200) |
| Caninet Size (mm*mm) | 800*800*105 | 1200*1200*105 | 1200*1200*105 | 1200*1200*105 |
| Cabinet Weight (kg) | 24(800*800) | 38(1200*1200) | 38(1200*1200) | 38(1200*1200) |
| Cabinet Resolution (px*px) | 120*120(800*800) | 144*144(1200*1200) | 120*120(1200*1200) | 72*72(1200*1200) |
| Input Voltage (V) | 110-220V | 110-220V | 110-220V | 110-220V |
| Waterproof Level | Front IP65 Back IP54 | Front IP65 Back IP54 | Front IP65 Back IP54 | Front IP65 Back IP54 |
| Working Environment | Outdoor | Outdoor | Outdoor | Outdoor |
| Cabinet Material | Fixed installation | Fixed installation | Fixed installation | Fixed installation |
